Insert existing part into new part
修改於: 五月 08,2017
評價:
下載: 349
評論:

規格

下載:349
描述:This macro was created to help NC Programmers utilize a SOLIDWORKS part model that has read-access only. This macro inserts the read-only engineering model into a read/write manufacturing part model that allows the NC Programmer to create tool-paths and maintain associativity to the engineering model. This is helpful for any Gold Solution NC Programming partner that stores their manufacturing data inside a SW Part (such as CamWorks). This technique is useful when NC Programmers have read-only access to the engineering model within PDM. This macro also has a .bmp included so it can be customized as a button with the SW UI.
    前置條件: SOLIDWORKS is running with the focus set on a Part (.sldprt)
  後置條件: A new part is created and the part that had the focus is now inserted into the new part. The Material from the original part has been copied to the new part.
SOLIDWORKS 版本： 2017
程式設計語言: SW_VBA




巨集可能包含病毒或其他安全性的威脅。SOLIDWORKS Corporation 尚未確認張貼在此網站上的巨集是安全的，或巨集是來自於可信任的來源。

下載 SOLIDWORKS 巨集。



(需要登入)
